Robot Turntable RV Reducer

Sample Validation Workflow

1. Pre-check application, model, ratio, torque, backlash, flange dimensions, input interface, and annual forecast before quotation.
2. Review drawings or current reducer datasheets to confirm mounting compatibility and hidden integration constraints.
3. Release sample order with agreed acceptance criteria for backlash, noise, thermal rise, runout, load test, and visual inspection.
4. Compare sample results against buyer-side robot or module test data, then freeze revisions before pilot production.
5. Move approved projects into repeat production with forecast, packaging, inspection records, and delivery cadence aligned.

Procurement Notes

• Send the existing reducer brand/model when the project is a replacement program; model number alone is useful but not enough for final approval.
• Include destination country, required delivery date, sample quantity, and annual forecast so lead time and pricing are realistic.
• For custom interfaces, attach revision-controlled drawings and mark dimensions that cannot change after robot joint approval.

RFQ Preparation Checklist

1. Turntable diameter and total mass
2. Mass moment of inertia
3. Index angle and time
4. Expected shock loads
5. Motion profile, acceleration, deceleration, duty cycle, shock case, and lifetime target
6. Sample acceptance method, pilot-lot quantity, annual forecast, destination, and required delivery date

Risk and Mitigation

• Bearing failure under eccentric loads: Verify the center of gravity and calculate worst-case eccentric loads during indexing.
• Application described too broadly: Tie the reducer choice to axis, load case, duty cycle, interface, and acceptance evidence before quotation.
• No internal owner for sample approval: Confirm who signs off fit, motion data, inspection report, and pilot release before samples ship.
